Research on distribution of aperture position error in multi-beam coherent imaging and its impact on image quality

ZHANG Yu; LUO Xiujuan; LIU Hui; CHEN Minglai; CHENG Zhiyuan; LAN Fuyang

doi:10.5768/JAO201940.0302001

Volume 40 Issue 3

May 2019

Turn off MathJax

Article Contents

Article Navigation > Journal of Applied Optics > 2019 > 40(3): 411-415

ZHANG Yu, LUO Xiujuan, LIU Hui, CHEN Minglai, CHENG Zhiyuan, LAN Fuyang. Research on distribution of aperture position error in multi-beam coherent imaging and its impact on image quality[J]. Journal of Applied Optics, 2019, 40(3): 411-415. doi: 10.5768/JAO201940.0302001

Citation:

ZHANG Yu, LUO Xiujuan, LIU Hui, CHEN Minglai, CHENG Zhiyuan, LAN Fuyang. Research on distribution of aperture position error in multi-beam coherent imaging and its impact on image quality[J]. Journal of Applied Optics, 2019, 40(3): 411-415. doi: 10.5768/JAO201940.0302001

Citation:

ZHANG Yu, LUO Xiujuan, LIU Hui, CHEN Minglai, CHENG Zhiyuan, LAN Fuyang. Research on distribution of aperture position error in multi-beam coherent imaging and its impact on image quality[J]. Journal of Applied Optics, 2019, 40(3): 411-415. doi: 10.5768/JAO201940.0302001

PDF( 862 KB)

Research on distribution of aperture position error in multi-beam coherent imaging and its impact on image quality

doi: 10.5768/JAO201940.0302001

Xi'an Institute of Optics and Precision Mechanics, CAS, Xi'an 710119, China

Received Date: 2018-08-15
Rev Recd Date: 2018-11-19
Publish Date: 2019-05-01

Abstract

Abstract

As the research of coherent imaging (Fourier telescopy) in the procedure from laboratory experiments to the real system, there are many factors that may impact on the realization. However, among the factors and analysis, there has not been a theoretical support for calibrating the aperture position error distribution and the error range. In this article, based on the optical transportation theory, the aperture position error distribution and its impact on image quality were analyzed. The paper also proposed the error range and carried out the experimental setups. The results demonstrate that the relative position error should be controlled less than 5%. To sum up, this article provide a theoretical method to analyze the design and the configuration of the real Fourier telescopy.
- coherent field imaging,
- Fourier telescopy,
- aiming accuracy,
- aperture position,
- imaging quality
